I will be calling this project the "Corsair 900D WWII Bomber Military Case Mod" we will be customizing the WWII Memphis Belle Bomber Military Case Mod into something special and added the "T2" touch to this new project.

In case you missed it, on Memorial Day Bill Owen posted Corsair 900D WWII Memphis Belle Bomber Military Case Mod Guide to hand off the Dremel to Anthony Reynolds AKA THRASHER2

https://www.youtube.com/watch?v=Nu3LV8-o6vY

http://techoftomorrow.invisionzone.com/index.php?/topic/171-corsair-900d-wwii-bomber-military-case-mod/


Hardware Specs

  • Intel Core i7 Extreme Edition Desktop Processor I7-965
  • Corsair TX850M Power Supply or a Huntkey X7 1200W Power Supply with custom Sleeved Cables
  • Gigabyte G1 Sniper or ASSASSIN X58 Motherboard
  • Corsair 900D Custom Painted WWll Bomber Case with Custom Grills and BOMB front item
  • Swiftech Custom Water Cooling solution
  • 2X Triple 120mm Radiator custom painted green
  • 2X GeForce GTX 780 Video Cards
  • Corsair Vengeance® — 12GB Triple Channel DDR3 Memory Kit (CMZ12GX3M3A2000C10)

Swiftech Parts List

Qty. 2 - The Komodo™NV-LE (Luxury Edition) Part Number: KOMODO-NV-LE

Qty. 1 - The Apogee™ XL Part Number: Apogee-XL

Qty. 2 - The MCP35X pump Part Number: MCP35X-BK

Qty. 2 - The MCRx20-XP (eXtreme Performance) series Part Number: MCR320-XP

Qty. 18 - ½” x ¾” Lok-Seal™ Compression Fitting Part Number: 3-4X1-2-G1-4-CF-BK

Qty. 4 - Lok-Seal Quick Disconnect Non Spill Couplings Part Number: QC-NS-BK

Qty. 6 - 90° Swivel Elbow Lok-Seal™ adapter Part Number: 90D-SWV-G1-4-MFA-BK

Qty. 4 - 90° Dual Swivel Elbow Lok-Seal™ adapter Part Number: 90D-DUAL-SWV-G1-4-MFA-BK

Qty. 4 - 45° Swivel Elbow Lok-Seal™ adapter Part Number: 45D-SWV-G1-4-MFA-BK

Qty. 4 - 15mm Lok-Seal™ Male/Female extension adapter Part Number: 15MM-G-1-4 MFA-BK

Qty. 2 - 4-Way Lok-Seal™ manifold: this 4-way manifold Part Number: 4W-G1-4-TA-BK

Special Items
Qty. 1 mnpctech 480 version of with 4x 120mm "Sniper" grill
